cat001.h File Reference
ASTERIX CAT001 - Monoradar Target Reports. More...
Include dependency graph for cat001.h:
This graph shows which files directly or indirectly include this file:
Go to the source code of this file.
Data Structures | |
| struct | ast_dataitem_001_020_t |
| Item I001/020 - Target Report Descriptor. More... | |
| struct | ast_dataitem_001_030_t |
| Data Item I001/030 - Warning/Error Conditions. More... | |
| struct | ast_dataitem_001_040_t |
| Data Item I001/040 - Measured Position in Polar Coordinates. More... | |
| struct | ast_dataitem_001_042_t |
| Data Item I001/042 - Calculated Position in Cartesian Coordinates. More... | |
| struct | ast_dataitem_001_060_t |
| Data Item I001/060 - Mode-2 Code Confidence Indicator. More... | |
| struct | ast_dataitem_001_120_t |
| Data Item I001/120 - Calculated Position in Cartesian Coordinates. More... | |
| struct | ast_dataitem_001_141_t |
| Data Item I001/141 - Truncated Time of Day. More... | |
| struct | ast_dataitem_001_170_t |
| Data Item I001/170 - Track Status. More... | |
| struct | ast_dataitem_001_210_t |
| Data Item I001/210 - Track Quality. More... | |
| struct | ast_datarecord_001_t |
| Data Record I001 - Monoradar Target Reports. More... | |
Typedefs | |
| typedef ast_dataitem_data_source_identifier_t | ast_dataitem_001_010_t |
| Data Item I001/010 - Data Source Identifier. More... | |
| typedef ast_dataitem_mode_3a_code_t | ast_dataitem_001_070_t |
| Data Item I001/070 - Mode-3/A Code in Octal Representation. More... | |
| typedef ast_dataitem_mode_3a_confidence_t | ast_dataitem_001_080_t |
| Data Item I001/080 - Mode-3/A Code Confidence Indicator. More... | |
| typedef ast_dataitem_mode_c_code_t | ast_dataitem_001_090_t |
| Data Item I001/090 - Mode-C in Binary Representation. More... | |
| typedef ast_dataitem_mode_c_confidence_t | ast_dataitem_001_100_t |
| Data Item I001/100 - Mode-C Code and Code Confidence Indicator. More... | |
| typedef ast_dataitem_track_number_t | ast_dataitem_001_161_t |
| Data Item I001/161 - Track Plot Number. More... | |
| typedef ast_dataitem_velocity_polar_t | ast_dataitem_001_200_t |
| Data Item I001/200 - Calculated Track Velocity in Ploar Coordinates. More... | |
Enumerations | |
| enum | ast_conventional_radar_target_type_t { AST_CONVENTIONAL_RADAR_TARGET_PLOT = 0, AST_CONVENTIONAL_RADAR_TARGET_TRACK = 1 } |
| enum | ast_radar_detection_type_t { AST_RADAR_DETECTION_NO = 0, AST_RADAR_DETECTION_PSR = 1, AST_RADAR_DETECTION_SSR = 2, AST_RADAR_DETECTION_PSR_SSR = 3 } |
| enum | ast_radar_emergency_type_t { AST_RADAR_EMG_DEFAULT = 0, AST_RADAR_EMG_7500 = 1, AST_RADAR_EMG_7600 = 2, AST_RADAR_EMG_7700 = 3 } |
| enum | ast_conventional_radar_track_type_t { AST_CONVENTIONAL_RADAR_TRACK_PSR = 0, AST_CONVENTIONAL_RADAR_TRACK_SSR_COMBINED = 1 } |
Functions | |
| const char * | ast_dataitem_001_get_name (const ast_dataitem_type_t type) |
| Get name function. More... | |
| ast_dataitem_001_020_t | ast_dataitem_001_020_decode (const ast_dataitem_t di) |
| Decode function. More... | |
| ast_dataitem_t | ast_dataitem_001_020_encode (unsigned char *const buffer, const size_t buf_size, const ast_dataitem_ex_t xdi) |
| Encode function. More... | |
| void | ast_dataitem_001_020_get_summary (char *summary, const size_t summary_size, const ast_dataitem_t di) |
| Get Summary function. More... | |
| void | ast_dataitem_001_020_get_detail_html (char *detail, const size_t detail_size, const ast_dataitem_t di) |
| Get detail function. More... | |
| ast_dataitem_001_040_t | ast_dataitem_001_040_decode (const ast_dataitem_t di) |
| Decode function. More... | |
| ast_dataitem_t | ast_dataitem_001_040_encode (unsigned char *const buffer, const size_t buf_size, const ast_dataitem_ex_t xdi) |
| Encode function. More... | |
| void | ast_dataitem_001_040_get_summary (char *summary, const size_t summary_size, const ast_dataitem_t di) |
| Get summary function. More... | |
| void | ast_dataitem_001_040_get_detail_html (char *detail, const size_t detail_size, const ast_dataitem_t di) |
| Get detail function. More... | |
| ast_dataitem_001_042_t | ast_dataitem_001_042_decode (const ast_dataitem_t di) |
| Decode function. More... | |
| ast_dataitem_t | ast_dataitem_001_042_encode (unsigned char *const buffer, const size_t buf_size, const ast_dataitem_ex_t xdi) |
| Encode function. More... | |
| void | ast_dataitem_001_042_get_summary (char *summary, const size_t summary_size, const ast_dataitem_t di) |
| Get summary function. More... | |
| void | ast_dataitem_001_042_get_detail_html (char *detail, const size_t detail_size, const ast_dataitem_t di) |
| Get detail function. More... | |
| ast_dataitem_001_141_t | ast_dataitem_001_141_decode (const ast_dataitem_t di) |
| Decode function. More... | |
| ast_dataitem_t | ast_dataitem_001_141_encode (unsigned char *const buffer, const size_t buf_size, const ast_dataitem_ex_t xdi) |
| Encode function. More... | |
| void | ast_dataitem_001_141_get_summary (char *summary, const size_t summary_size, const ast_dataitem_t di) |
| Get summary funciton. More... | |
| void | ast_dataitem_001_141_get_detail_html (char *detail, const size_t detail_size, const ast_dataitem_t di) |
| Get detail function. More... | |
| ast_dataitem_001_170_t | ast_dataitem_001_170_decode (const ast_dataitem_t di) |
| Decode function. More... | |
| ast_dataitem_t | ast_dataitem_001_170_encode (unsigned char *const buffer, const size_t buf_size, const ast_dataitem_ex_t xdi) |
| Encode function. More... | |
| void | ast_dataitem_001_170_get_summary (char *summary, const size_t summary_size, const ast_dataitem_t di) |
| Get summary function. More... | |
| void | ast_dataitem_001_170_get_detail_html (char *detail, const size_t detail_size, const ast_dataitem_t di) |
| Get detail function. More... | |
| ast_dataitem_001_210_t | ast_dataitem_001_210_decode (const ast_dataitem_t di) |
| Decode function. More... | |
| void | ast_dataitem_001_210_get_summary (char *summary, const size_t summary_size, const ast_dataitem_t di) |
| Get summary function. More... | |
| void | ast_dataitem_001_210_get_detail_html (char *detail, const size_t detail_size, const ast_dataitem_t di) |
| Get detail function. More... | |
| ast_sacsic_t | ast_datarecord_001_get_sacsic (const ast_datarecord_t dr) |
| Get SAC/SIC function. More... | |
| ast_msgtype_t | ast_datarecord_001_get_msgtype (const ast_datarecord_t dr) |
| Get message type function. More... | |
| ast_tracknum_t | ast_datarecord_001_get_tracknum (const ast_datarecord_t dr) |
| Get track number function. More... | |
| ast_squawk_t | ast_datarecord_001_get_squawk (const ast_datarecord_t dr) |
| Get Mode-3/A code function. More... | |
| ast_altitude_t | ast_datarecord_001_get_flightlevel (const ast_datarecord_t dr) |
| Get flight level function. More... | |
| ast_polar_coordinate_t | ast_datarecord_001_get_polarcoord (const ast_datarecord_t dr) |
| Get polar coordinate function. More... | |
| ast_datarecord_001_t | ast_datarecord_001_disassemble (const ast_datarecord_t dr) |
| Disassemble function. More... | |
| ast_datarecord_t | ast_datarecord_001_assemble (unsigned char *const buffer, const size_t bufsize, const ast_datarecord_001_t dr, const ast_uap_t uap) |
| Assemble function. More... | |
| ast_datablock_t | ast_datablock_001_mixuap_decode (const unsigned char *const buffer, const size_t bufsize) |
| Decode CAT001 data block with data records using mixed track and plot UAP. More... | |
Detailed Description
ASTERIX CAT001 - Monoradar Target Reports.
- Note
- This implementation is based on ASTERIX CAT001 version 1.0
Macro Definition Documentation
◆ ast_dataitem_001_050_get_size
| #define ast_dataitem_001_050_get_size ast_dataitem_mode_2_code_get_size |
Get size function.
◆ ast_datarecord_001_get_callsign
| #define ast_datarecord_001_get_callsign 0 |
Get callsign function.
◆ ast_datarecord_001_get_coordinate
| #define ast_datarecord_001_get_coordinate 0 |
Get coordinate function.
◆ ast_datarecord_001_get_heading
| #define ast_datarecord_001_get_heading 0 |
Get heading function.
◆ ast_datarecord_001_get_icaoaddr
| #define ast_datarecord_001_get_icaoaddr 0 |
Get ICAO 24-bit address function.
◆ ast_datarecord_001_get_speed
| #define ast_datarecord_001_get_speed 0 |
Get speed function.
◆ ast_datarecord_001_get_timeofday
| #define ast_datarecord_001_get_timeofday 0 |
Get time of day function.
Function Documentation
◆ ast_datablock_001_mixuap_decode()
| ast_datablock_t ast_datablock_001_mixuap_decode | ( | const unsigned char *const | buffer, |
| const size_t | bufsize | ||
| ) |
Decode CAT001 data block with data records using mixed track and plot UAP.
Decode CAT001 data block with data records using mixed track and plot UAP
- Parameters
-
buffer Buffer to read datablock data bufsize Buffer size
- Returns
- Data block, whose "valid" field will be set when data decoding is successful or failed.
◆ ast_dataitem_001_get_name()
| const char* ast_dataitem_001_get_name | ( | const ast_dataitem_type_t | type | ) |
Get name function.
◆ ast_datarecord_001_get_flightlevel()
| ast_altitude_t ast_datarecord_001_get_flightlevel | ( | const ast_datarecord_t | dr | ) |
Get flight level function.
◆ ast_datarecord_001_get_msgtype()
| ast_msgtype_t ast_datarecord_001_get_msgtype | ( | const ast_datarecord_t | dr | ) |
Get message type function.
◆ ast_datarecord_001_get_polarcoord()
| ast_polar_coordinate_t ast_datarecord_001_get_polarcoord | ( | const ast_datarecord_t | dr | ) |
Get polar coordinate function.
◆ ast_datarecord_001_get_sacsic()
| ast_sacsic_t ast_datarecord_001_get_sacsic | ( | const ast_datarecord_t | dr | ) |
Get SAC/SIC function.
◆ ast_datarecord_001_get_squawk()
| ast_squawk_t ast_datarecord_001_get_squawk | ( | const ast_datarecord_t | dr | ) |
Get Mode-3/A code function.
◆ ast_datarecord_001_get_tracknum()
| ast_tracknum_t ast_datarecord_001_get_tracknum | ( | const ast_datarecord_t | dr | ) |
Get track number function.
